T6 and T8 series

Quick-Tech's series of CNC lathes with tool head (BMT-55) includes the T6 Compact/Twin, T8 Hybrid Y-axis and T8 Twin/Classical.
The T8 series is designed to perform heavy machining with high accuracy and precision. The series combines an extremely powerful turret head and flexible tooling system, synchronized spindles, a 25bar high pressure pump, a 360° free rotating B-axis for threading and drilling at any angle, and a Y-axis is available as an option.
The series offers a tool head and 8" or 10" chuck.
The instrument head is mounted on an additional wedge at 75° on the X-axis as part of the hull casting. Both X and Y axes have wide, hardened linear guides to ensure stability and accuracy. Control on the Y-axis provides multitasking capabilities on rotating tools and enhances various types of machining. With a Y-axis stroke of 80mm=±40mm a wide range of workpieces can be machined efficiently.

The T6 series is designed for easy turning of mass production parts, covering their high demands through a large selection of options (e.g. reinforced tool head BMT-55). Machines in this series can be used with either a 6" or 8" chuck.
The T6 Twin model is equipped with a second spindle in order to machine the second side of the workpieces.
Rotary tools and C-axis work are available with milling, drilling and tapping capabilities.

Марка:QUICKTECH

Описание

[su_spoiler title="T8 Hybrid Y-axis" anchor="T8 Hybrid Y-axis"]

Mitsubishi M720 Control/Fanuc (optional)
Dimensions of the main spindle	Spindle size [mm]	65
	Stroke above base [mm]	500.0
	Stroke over cross slide [mm]	300.0
	Max. turning length [mm]	350.0
	Max. spindle bore [mm]	66.0
	Speed [rpm]	4000
	Tilt	75˚
	Hydraulic pressure min./max. [kg/cm2]	5/45
	Chuck size	KK6-185E-60B Collet/A2-6 Chuck
Dimensions of the second spindle	Chuck size	KK5-173E-42B Collet/A2-5 Chuck
	Spindle bore [mm]	32.0
	Power [rpm]	4000
Axis	Screws on X/Z/X1/Y1/Z1 axes	Φ32 x P10
	Stroke of linear guides on X/Z/X1/Z1 axes [mm]	35.0
	Feed on X/Z/X1/Y1/Z1 axes [M/min]	30
Instrumental system	1 workstation
	System	BMT-55 Instrument head
	Number of instruments	12 (includes external/internal machining/rotary tools)
	Tool holder [mm]	○25 ○25 / 32
	2 workstation
	System	Platform
	Number of instruments	5 for external machining x 9 for internal machining x 12 rotary tools
	B axis (optional)	360˚
	Tool holder [mm]	○20 ○20
Motor	Motor of the main spindle	Mitsubishi AC Servo 11kw
	Motor of the additional spindle	Mitsubishi AC Servo 5.5kw
	Servo motor on X/Z axle	Mitsubishi AC Servo 1.5kw(B) / 1.5kw
	Servo motor on X1/Y1/Z1 axles	Mitsubishi AC Servo 1.5kw / 1.5kw(B) / 1.5kw
	Motor of the chip conveyor	1/2 hp
	Hydraulic pump motor	1 hpx2
Positioning	Positioning	0.001mm
Cooling system	Type cooling motor	Max.pressure：5bar(4.6kg/cm²) Leakage：75L/min
	Type hydraulic motor	Max.pressure：25bar(55kg/cm²) Leakage：30L/min
	Tank capacity	240L
Lubrication	Capacity	2L
Lubrication	Pump pressure	15kg/cm²
Machine size	Length without/with chip conveyor	2850 mm / 3550 mm
	Width/Height	1950mm / 1970 mm
	Weight	6100kg

[/spoiler] [su_spoiler title="T8 Twin/Classical" anchor="T8 Twin/Classical"]

Mitsubishi Management M70
Machine type		T8-Twin-Y	T8-Twin	T8-Classical
Dimensions of the main spindle	Hole size	65mm
	Stroke above the base	500.0mm
	Stroke above the cross slide	300.0mm
	Max. turning length	350.0mm
	Max. spindle bore	66.0 mm
	Speed	4000 rpm
	Tilt	75˚
	Hydraulic pressure min./max.	5/30 kg/cm²
	Chuck size	KK6-185E-60B Collet/A2-6 Chuck
Dimensions of the second spindle	Chuck size	KK5-173E-42B Collet/A2-5 Chuck		–-
	Open	32.0 mm		–-
	Power	4000 rpm		–-
Stroke & Feed	X/Z axis stroke	230.0mm/400.0mm
	Stroke on Z1 axis	385.0mm		–-
	Y axis	80 mm = ± 40 mm	–-	–-
Axis	X/Z axis ATS	Φ32 x P10
	Linear guides on X/Z axes	35.0mm
	Feeding on X/Z/X1/Y1/Z1 axes	30M/min
Instrumental system	System	BMT-55 Instrument head
	Number of instruments	12 (including external/internal machining tools/rotary tools)		Servo tool head 12 tools
	Toolholder	○25mm ○25mm / 32mm
Motor	Motor of the main spindle	Mitsubishi AC Servo 11kw
	Motor of the additional spindle	Mitsubishi AC Servo 3.7kw
	Servo motor on X/Z axle	Mitsubishi AC Servo 1.5kw(B)
	Servo motor on Z1 axis	Mitsubishi AC Servo 1.5kw
	Motor of the chip conveyor	1/4 hp		–-
	Hydraulic pump motor	2 hp		–-
Positioning	Positioning	0.005mm		–-
Cooling system	Type cooling motor	Max. pressure：5bar(4.6kg/cm²) Leakage：75L/min
	Type hydraulic motor	Max. pressure：25bar(55kg/cm²) Leakage：30L/min
	Tank capacity	240L
Lubrication	Tank capacity	2 L
	Pump pressure	15 kgf/cm²
Dimensions of the machine	Length without/with chip conveyor	2450mm/3350mm	2450mm/3350mm	2350mm / 3250mm
	Width/Height	1650mm/1750mm	1650mm/1750mm	1650mm / 1750mm
	Weight	5900 kg	5900 kg	5700kg

[/spoiler] [su_spoiler title="T6 Compact/Twin" anchor="T6 Compact/Twin"]

Mitsubishi Management M70
Machine type		T6-Twin	T6-Compact
Dimensions of the main spindle	Hole size	42mm
	Stroke above the base	400.0mm
	Stroke above the cross slide	230mm
	Max. turning length	300mm
	Max. spindle bore	44.0mm
	Speed	4000 rpm
	Tilt	45˚
	Hydraulic pressure min./max.	5/30 kg/cm²
	Chuck size	KK5-173E-42B
Dimensions of the second spindle	Chuck size	KK4-163E-30B
	Hole size	32.0 mm
	Power	4000 rpm
Stroke & Feed	X/Z axis stroke	200.0mm/300mm
	Stroke on Z1 axis	300.0mm
	ATC on X/Z/X1/Y1/Z1 axis	X / Z Φ32 x P10
	Linear guides on X/Z/X1/Z1 axes	X / Z 35.0mm
	Feeding on X/Z/X1/Y1/Z1 axes	30m/min
Instrumental system	System	BMT-55 Instrument head
	Number of instruments	Servo tool head with 12 tools
	Toolholder	○25mm ○25mm
Motor	Motor of the main spindle	Mitsubishi AC Servo 7.5KW
	Motor of the second spindle	Mitsubishi AC Servo3.7kw	–-
	Servo motor on X/Z axle	X / Z Mitsubishi AC Servo 1.5kw
	Servo motor on X1/Y1/Z1 axles	Z1 = Mitsubishi AC Servo 1.0kw	–-
	Motor of the chip conveyor	1/4 hp
	Hydraulic pump motor	1HP
Positioning	Positioning	0.001mm
Cooling system	Type cooling motor	Max. pressure：5bar(4.6kg/cm²) Leakage：75L/min
	Tank capacity	142L
Lubrication	Tank capacity	2 L
	Pump pressure	15 kgf/cm²
Dimensions of the machine	Length without/with chip conveyor	2600mm / 3200mm
	Width/Height	1300 / 1860mm
	Weight	3500 kg	3000 kg
