    MB-V series

    Of all OKUMA vertical centers, the MB-V series sets the bar for efficiency, performance and high speed. This machine is among the fastest in the industry. Impressive thermal stability and minimal table cantilever allow for tight tolerances and exceptional accuracy. The ergonomic design of the MB-V series with front access needs minimal floor space and gives maximum results. In addition, the MB-V series is environmentally friendly requiring no hydraulic fluid. Optimized design based on finite element analysis (FEM) and fast spindle strokes with Hi-G acceleration combine to create a robust, flexible machine that promises speed and accuracy time and time again.

    Марка:Okuma
    [su_spoiler title="MB-46VA/B" anchor="MB-46VA/B"]
    Table size [mm] 760×460
    X-Y-Z axes [mm] 560 / 460/ 460
    Spindle speed [min-1] 8.000 [15.000/20.000/25.000/35.000]
    No. instruments 20 [32, 48]
    Power (VAC) [kW] 11/7.5 [22/18,5, 30/22, 15/11]
    Rapid traverse m/min 40/40/32
    Floor space W x D [mm] 1.900/1.950×2.715
    [/spoiler] [su_spoiler title="MB-56VA/B" anchor="MB-56VA/B"]
    Table size [mm] 1.300 x 560
    X-Y-Z axes [mm] 1.050/ 560/ 460
    Spindle speed [min-1] 8.000 [15.000/20.000/25.000/35.000]
    No. instruments 20 [32, 48]
    Power (VAC) [kW] 11/7.5 [22/18,5, 15/11]
    Rapid traverse m/min 40/40/32
    Floor space W x D [mm] 2.470 x 3.100
    [/spoiler] [su_spoiler title="MB-66VA/B" anchor="MB-66VA/B"]
    Table size [mm] 1.530 x 660
    X-Y-Z axes [mm] 1.500/ 660/ 660
    Spindle speed [min-1] 8.000 [15.000, 20.000, 25.000]
    No. instruments 20 [32, 48]
    Power (VAC) [kW] 11/7.5 [22/18.5, 30/22]
    Rapid traverse m/min 40/40/32
    Floor space W x D [mm] 2.940 x 3.265
    [/spoiler]
